RLS-2020A Outdoor/Indoor LiDAR, ONVIF-Profile S
20x20m PoE+ LiDAR sensor, ONVIF profile S compliant for outdoor and indoor high security applications
- Analytics recognising moving object’s size, location and distance from the unit
- Short-range 20x20m, customisable vertical or horizontal detection
- up to 8 detection zones with configurable sensitivity, target size and output
The REDSCAN mini-Pro RLS-2020A creates virtual detection walls or planes across 20x20 meters at 95 degrees and analyses a moving object's size, location and distance to determine an intrusion. Designed to work effectively in both outdoor and indoor environments, it is ideal to protect high-value assets and high-security buildings and perimeters.
Part of the award-winning REDSCAN series, the new RLS-2020A delivers highly-precise LiDAR detection and ultra-fast response times, meaning you can be assured that intrusions will be detected without delay. With a detection range of 20 x 20 m 95 degrees, it is ideal to protect high-value assets and high-security buildings and perimeters. In addition, it is compatible wih ONVIF Profile S and has additional outputs and protocols allowing seamless integration into your existing security infrastructure.
Warehouse
Museum/Gallery
Datacentre
Airport
Commercial
Rail
The REDSCAN mini-Pro RLS-2020A creates virtual detection walls or planes across 20x20 meters at 95 degrees and analyses a moving object's size, location and distance to determine an intrusion. Designed to work effectively in both outdoor and indoor environments.
Filters
Filters
Technology
Detection Range
Advanced Features
Communication
Mounting
Intrusion Detection
up to 20x20m or 95° 30m radius, indoor / outdoor LiDAR sensor, wired /PoE
- LiDAR with customisable detection area up tp 20x20m or 95° 30m radius (ver. 3)
- Creates virtual walls and planes for a versatile indoor/ outdoor protection
- Unique algorithm detecting the size, distance and speed of the objects
- PoE compliant and integrated with most VMS platforms
Indoor laser scanner, 20m20m 95 degree coverage. Features customisable ‘virtual’ wall or pane.
- Multi-angle adjustment shell structure
- Unique detection algorithm
- Automatic area setting function
- Advanced area setting
- Grade 3 Certification
- Analytics recognising moving object’s size, speed and distance from the unit
- 30x60m, customisable vertical or horizontal detection
- Built-in assistance camera, for easy installation and alarm event review
- up to 8 independent zones with configurable sensitivity, target size and output
- Grade 3 Certification
- Analytics recognising moving object’s size, speed and distance from the unit
- Long-range, 50x100m, customisable vertical or horizontal detection
- Built-in assistance camera, for easy installation and alarm event review
- up to 8 detection zones with configurable sensitivity, target size and output
20x20m PoE+ LiDAR sensor with FHD camera, ONVIF profile S compliant for outdoor and indoor high security applications
- Analytics recognising moving object’s size, location and distance from the unit
- Built-in FHD camera with IR LED for alarm verification
- Short-range 20x20m, customisable vertical or horizontal detection
- up to 8 detection zones with configurable sensitivity, target size and output
- 1
Specifications
See details
Details
Product Range
Infrared Laser Scan
Model Code
RLS-2020A
Detection method
Laser
Detection Coverage
20 x 20m, 95 degree (approx. 65 x 65 ft.)
Detectable speed
0.125 degrees / within 100 msec. to 15 min. / 0.25 degrees / within 50 msec. to 15 min.
Power input
19.2-30 VDC, PoE (IEEE 802.3 at compliant)
Current draw
420 mA max. (24 VDC), 10 W max. (PoE)
Alarm period
Approx. 2 second delay timer
Operation temperature
-40°C to 60°C ( -40°F to 140°F)
IP rating
IP66
Installation Method (indoor/outdoor)
Indoor/Outdoor
Mounting height
Indoor: 2 m (6.7 ft.) or higher / Outdoor : 4 m (13 ft.) or higher (Recommended)
Dimensions
202.6 x 206.7 x 163.5 mm max. (8.0 × 8.1 × 6.4 inch)
Laser protection class
Class 1
Protocol
UDP/ TCP/ HTTP/ HTTPS/ IPV4/ IPV6/ DNS/DHCP/ SNMPv1-v3/ NTP/ WS-Discovery/ ONVIF/IEEE802.1X
Communication port
Ethernet RJ-45 10BASE-T/100BASE-TX (Auto negotiation)
