REDWALL SIP-4010 Outdoor long range motion sensor for CCTV
- Advanced detection algorithm
- Designed to trigger CCTV systems
- Two independent detection zones far/near
- Active infrared antimasking and vandal-resistant
The SIP-4010 is part of the REDWALL-V Series and is designed for use in small and mid-sized outdoor areas. This model provides a detection range of 40x10 meters (LxW) which makes it ideal for covering long and relatively wide site areas. It has an intelligent detection system that uses data on the ambient environment, such as temperature and illuminance conditions, to automatically adjust the sensitivity. Mechanisms for easy installation enable accurate adjustment of the detection area at setup, which results in more reliable operation.
The optional AVF-1 Area View Finder allows the installer to visually identify the detection area.
Warehouse
Manufacturing
Commercial
Utilities
Substation
Power plant
Filters
Filters
Technology
Detection Range
Advanced Features
Communication
Mounting
Intrusion Detection
- Intelligent PIR detection system
- Designed to trigger CCTV systems
- Two independent detection zones far/near
- Active infrared antimasking and vandal-resistant
- Advanced detection algorithm
- Three dual pyro-elements with patented Double Conductive Shielding
- Two independent detection zones far/near
- AIR antimasking and vandal-resistant
- Intelligent PIR detection system
- Designed to trigger CCTV systems
- Two independent detection zones far/near
- Active infrared antimasking and vandal-resistant
- Intelligent PIR detection system
- Designed to trigger CCTV systems
- Two independent detection zones far/near
- Active infrared antimasking and vandal-resistant
50x30 synthesized Intelligent IP wide angle detector. Features 3 outputs, far/near/creep zones.
- Double Dual/one Quad pyro-elements with patented Double Conductive Shielding
- Advanced detection algorithm
- Reinforced polycarbonate housing
- Equipped with anti rotation & anti-masking functions to prevent vandalism
- Double Quad pyro-elements with patented Double Conductive Shielding
- Advanced detection algorithm
- Reinforced polycarbonate housing
- Equipped with anti rotation & anti-masking functions to prevent vandalism
- Intelligent PIR detection system
- Can be Integrated with most VMS platforms
- Two independent detection zones far/near
- Active infrared antimasking and vandal-resistant
- Advanced detection algorithm
- Designed to trigger CCTV systems
- Three independent detection zones far/near/creep
- Active infrared antimasking and vandal-resistant
- Intelligent PIR detection system
- Can be Integrated with most VMS platforms
- Two independent detection zones far/near
- Active infrared antimasking and vandal-resistant
- 1
- 2
Specifications
See details
Details
Product Range
REDWALL Series
Model Code
SIP-4010
Detection method
Passive infrared
Detection Coverage
40 x 10 m (130 x 33 ft.)
Sensitivity
Far : SH/H/M/L Near : SH/H/M/L
Power input
11-26 VDC 22-26 VAC, 22-26 VDC/AC with optional heating unit
Current draw
40 mA max. (12 VDC) 75 mA max. (24 VAC), 415 mA max. (24 VAC) with optional heating unit
Alarm period
Approx. 2 sec.
Warm-up period
Approx. 60 sec.
Alarm output (R)
N.O., N.C., 28 VDC 0.2 A max.
Trouble output
N.C., 28 VDC 0.2 A max.
Tamper output
N.C., 28 VDC 0.1 A max.
Operation temperature
"-25 to +60°C, -40 to +60°C with optional heating unit (-13 to +140°F, -40 to +140°F with optional heating unit)"
IP rating
Main unit : IP65 Chassis : IP55
Installation Method (indoor/outdoor)
Outdoor
Mounting height
2.3 to 4 m (7.6 to 13 ft.)
Weight
1.2 kg (42 oz)
Dimensions
227 x 102 x 266 mm (9.0 x 4.0 x 10.5 in.)
